Grill model: P4BL (2002)

FREE Shipping over $79 PlayButton
Broilmaster grill

Genuine Broilmaster factory replacement parts


Here's the parts we have for model P4BL (2002)
Home     Contact Us     Privacy Policy     Return Policy     Shipping Policy     About Us
Orders $79 and over get Free USA shipping


1
B057805 Bridge Pin, Fits all models. MORE...

$1.71
2
B057804 Hinge Pin, Fits all models. MORE...

$1.71
3
B072696 Stainless steel warming rack (Retract-A-Rack). Fits P4 and D4.

Note: Part B072696 is the factory authorized replacement for the following parts, which are no longer available:

  • B060757
MORE...


$56.36
4
WM-GRID3 Aftermarket premium grade solid stainless steel cooking grid with 1/4" rods for Broilmaster and Warm Morning (by Locke Stove) size 4 grill head. Fits: P4, D4, U4, G4. An economical alternative to the other available Broilmaster grids. These grids are comparable to Broilmaster's porcelain steel grids, which are no longer available.

Sold individually, two (2 required).
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

$49.81
4
62203 Cast iron "water fall style/multiple level" cooking grids (set of 3). Porcelain treated, glossy finish.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

$226.10
4
DPA112 Heavy duty stainless steel cooking grids for size 4 grill head.
  • Heavy gauge 5/16" stainless rods
  • Restaurant quality stainless steel
  • 2 piece set
  • Fits P4, D4, U4
  • Same as part B101320 (was sold individually)

Note: Part DPA112 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B101321
  • BM:DPA102
  • BM:DPP12
MORE...


$156.13
6
DPA107 Grid Lifter Kit. Also replaces kit part# B064539. NOTE: The photo of the part is currently incorrect. The manufacturer has changed the design to a one-piece 7" long 1 5/8" wide stainless-steel grid lifter with a round hanging hole on the handle end.

Note: Part DPA107 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B064539
MORE...


$27.92
7
B069756 Hose and Regulator W/ Q.C.C. (female pipe fitting), fits all BRM LP models to 1999, SBG2500, 2501, 2801 MORE...


$29.48
9
B100098 Grill top height adjuster bar knob, Fits All Models (was B225). MORE...

$6.50
10
DPA106 Adjustable Lid Stop Kit, All Models. Also replaces part #s B100421, B101231, B061281 and 061281.

Note: Part DPA106 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B076521
  • BM:B100421
  • BM:B101231
MORE...


$32.38
11
B100514 Twin Natural Valve Assembly (male flare fitting). Used on all grills built after 2002 (Except T and R Seies).
    Includes:
  • B100517 Manifold mounting plate
  • B069003 (2) natural gas manifolds with orifices
  • B076789 Dual valve assembly

Note: Part B100514 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B070502
MORE...


$95.62
11
B100515 Valve - LP w/ Hose and Regulator fits P3, P4, D3, D4.
Also replaces part B070501, which has been discontinued by Broilmaster.

Note: Part B100515 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B070501
MORE...


$115.42
11A
B076789 Twin natural gas valve assembly. Fits P3/4 MORE...

$54.02
11B
B069002 LP Manifold W/Orifice, Fits P3, P4, D3, D4. Sold individually. See part number BKC1001 for set of two.

Note: Part B069002 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B056649
MORE...


$22.88
11B
B069003 NATURAL GAS Manifold W/Orifice, Fits P3, P4, D3, D4. Sold individually. See part number BCK1000 for set of two.

Note: Part B069003 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B056647
MORE...


$22.88
11C
B100517 Plate, Orifice Mounting, Fits P3, P4, D3, D4.

Note: Part B100517 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B064787
MORE...


$6.41
14
TG-2B Universal bolt-on heat indicator replaces most factory installed indicators with 1 1/2" bolt centers. Stainless steel case.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

$11.95
15
B102492 Stainless steel lid handle. Requires mounting bolt holes to be on 21 inch centers. Includes mounting bolts. Overall length of the handle is 22 1/4" long. When using this handle to replace the longer 24" handle, drilling new holes is required.

Note: Part B102492 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B076313
  • BM:B076793
MORE...


$34.30
16
B073097 Foam Grip for S/S Handles, Fits P3, P4, P5. MORE...

$10.64
17
B067449 Briquet Rack - This briquette rack is porcelain enameled steel rods; however, there have been times when the manufacturer made these in stainless steel without a price difference. Fits P4/D4. See partDPA117 for Ceramic Flare Busters. MORE...

$41.75
18
WM-BRN2-8 Exact fit aftermarket cast iron Bowtie Burner and twin venturi assembly for older Broilmaster and Warm Morning (by Locke Stove) grills. This burner and curved venturi fits smaller grills with upfront controls. Known to fit D4, S4, U4, U5 models.
    Includes:
  • One (1) cast iron burner
  • One (1) plate steel twin venturi
  • All necessary gaskets and scews. MORE...

$144.11
18
DPP102 Stainless steel burner and venturi assembly for D4, P4, U4, U5.
Also replaces part# B070435 and B100512.

Note: Part DPP102 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B070435
  • BM:B100512
MORE...


$115.63
19
B100446 Collector Box (Electronic Ignitor), electrode, and connector wire with female spade end. Please refer to DPP116 Kit if ground wire needed and two screws; does include sleeve # B069743. Fits P3/P4

Note: Part B100446 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B072701
MORE...


$27.72
19A
B100402 Collector box kit for P3/P4 and D3/D4 with electronic igniters.

$34.30
19B
DPP20 Electronic igniter kit.

$56.36
20

B063065 Radiation Shield (Heat & Wind Deflector), Fits All Models. MORE...


$40.30
21
B069743 Collector Box Spacer, Fits P 3/4 D 3/4/5

Note: Part B069743 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B069343
MORE...


$4.68
23
B072218 Electronic ignitor head with two (2) male spade connectors. Fits 3/P4/P5/D3/D4
  • Uses 1 AA battery (not included)
  • Requires 7/8" mounting hole MORE...

$48.51
24
B069747 Ground Lug, Fits All Models MORE...

$3.21
25
B072684 Ground wire with female spade ends for battery-operated ignitors; 12" long. Fits All Electronic Models MORE...

$6.50
26
B100752 Control panel and label assembly, stainless steel (electronic ignitor), includes label and shield B100731. Fits P4

Note: Part B100752 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B073073
  • BM:B100153
  • BM:B100754
MORE...


$74.45
26
B101518 Stick-on control panel label for D4, P4, and other size 4 grills.

Note: Part B101518 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B072197
MORE...


$17.27
27
B070084 Knob, Black (New Style), Fits P3/4/4, SR3, D3/4/5/2.
Also replaces part# B070286, which no longer available.
  • Off position D-Value: 3 o'clock
  • Knob diameter: 1 5/8"
  • Socket diameter: 5/16"
  • Knob shaft: 1/2"

Note: Part B070084 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B070286
MORE...


$10.12
29
B073963 Shelf Pin and Nut, Fits All Models MORE...

$3.35
32
B662325 Space Lid Stop, Fits All Models MORE...

$3.35
40
B906236 Burner Stabilizer Kit. Fits pre 2002 grills.

Note: Part B906236 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B906180
MORE...


$10.12
41
B905048 Stabilizer Bracket, Fits All Carts MORE...

$6.50
99
B053585 Hugga-Rack Rotisserie kit, turns standard Rotisserie into Hugga-Rack.
  • Does not pierce meat. Clamps for the retention of juices
  • Fits P3/D3 and P4/D4 grills. Complete rotisserie set
  • Contains: grid backets, hugga-rack grids, spit rod, center frame, hardware.Does not include rotisserie motor MORE...

$154.10
99
BCK1000 Conversion Kit, LP to NATURAL GAS. Fits P3, P4, P3S, D3, D4. Includes:
  • Two (2) B069003 NG manifolds with orifices
  • One (1) conversion label B100033
  • Gas conversion instructions

Note: Part BCK1000 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B100243
MORE...


$38.30
99
BCK1001 Conversion Kit, Natural Gas to LP. Fits P3, P4, P3S, D3, D4. Includes:
  • Two (2) B069002 LP manifolds with orifices
  • One (1) conversion label B100273
  • Gas conversion instructions

Note: Part BCK1001 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B100239
MORE...


$38.30
99
BCK1002 Conversion Kit, LP to Natural Gas. Fits P3, P4, P3S, D3, D4. Includes:
  • Two (2) B069003 NG manifolds with orifices
  • One (1) NG12 12' Quick Disconnect Sturgis Hose Kit
  • NG hose has 3/8" inside diameter
  • One (1) conversion label B100033
  • Gas conversion instructions

Note: Part BCK1002 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B100244
MORE...


$108.67
99
BCK1003 Conversion Kit, natural gas to LP. Fits P3, P4, P3S, D3, D4. Includes:
  • Two (2) B069002 LP manifolds with orifices
  • One (1) B069756 LP hose and regulator
  • One (1) conversion label B100273
  • Gas conversion instructions

Note: Part BCK1003 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B100240
MORE...


$70.01
99
BCK1010 Conversion Kit, LP to Natural Gas. Fits P4X, H3X (P3X 2015 and newer) grill heads. Includes:
  • One (1) B101421 dual natural gas valve assembly
  • Two (2) P265 orifices #49 drill size
  • One (1) Conversion label NG B100033
  • Gas conversion instructions MORE...

$50.51
99
BCK1011 Conversion Kit, Natural Gas to LP gas. Fits P4X, H3X (P3X 2015 and newer) grill heads. Includes:
  • One (1) B069756 LP hose & regulator
  • One (1) B101420 dual LP valve assembly
  • Two (2) P182 orifices #55 drill size
  • One (1) Conversion label LP B100273
  • Gas conversion instructions MORE...

$78.12
99
DPA109 Deluxe black full-length cover for P, D, R, S, and T series grills with one stationary side shelf.
  • Broilmaster premium cover
  • Deluxe heavy duty PVC/Polyester material
  • Custom fitted for listed models
  • Top to bottom: 41"
  • Side to side: 54" (a little narrower at top)
  • Front to back - Top: 14"
  • Front to back - Bottom: 18" MORE...

$74.45
99
DPA110 Deluxe black full-length cover for P, D, R, S, and T series grills with two stationary side shelves.
  • Broilmaster premium cover
  • Deluxe heavy duty PVC/Polyester material
  • Custom fitted for listed models.
  • 40 3/8" tall
  • 61 3/8in side-to-side
  • 21 1/2" front-to-back MORE...

$81.79
99
DPA51 Heavy Duty Traditional Rotisserie. Includes:
  • B100932 Rotisserie Motor
  • B100078 Motor Bracket (includes screws and wing nuts)
  • B076850 Meat Forks (1 pair)
  • B076849 Locator Sleeve (AKA spit rod bushing)
  • B076851 Spit rod
  • B076854 Spit rod handle and thumbnut
  • B076852 Counter balance assembly. Replaces part# B076706.

Note: Part DPA51 is the factory authorized replacement for the following parts, which are no longer available:

  • BM:B076706
MORE...


$159.16
99
DPA8 Deluxe black full-length cover for P, D, R, S, and T series grills with no stationary side shelves.
  • Broilmaster premium cover
  • Deluxe heavy duty PVC/Polyester material
  • Custom fitted for listed models. MORE...

$71.08
?
45887 Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks. MORE...

$24.95
?
62203 Cast iron "water fall style/multiple level" cooking grids (set of 3). Porcelain treated, glossy finish.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

$226.10
?
TG-1B Universal clip-on temperature gauge fits most grills. Find out if your grill is still hot at a glance.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

$6.70
?
DPA117 Flare Buster Flat Ceramic Pads; consist of ten pieces, three of which are different size pieces. For P4, H4, D4. Requires B067449 Rack if replacing flavor screen. MORE...

$75.17
?
DPP116 Collector Box Kit - (Mounts to Burner). Includes collector box/electrode/connector wire, ground wire and screws. Does not include sleeve # B069743. Fits: P3X, P4X, H3X, H4X all Q3X 2012 with H burner. MORE...

$29.90
?
03500 36" wire with two female spade connectors for side burner igniters (not for use with rotary or piezo ignitors).
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

$5.42
?
IG-18B 20" igniter wire with two (2) female spade connectors.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

$4.93
