Grill model: H3XN

2

TG-2B Universal bolt-on heat indicator replaces most factory installed indicators with 1 1/2" bolt centers. Stainless steel case.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

3

B070486 Stainless steel Handle (Handle Only) -- See B076793, Fits P4/D4.
Requires mounting bolt holes to be on 21 inch centers. The overall length of the handle is 22 1/4". When using this handle to replace the longer 24" handle, drilling new holes is required.

Note: Part B070486 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B100811

MORE...

4

B073097 Foam Grip for S/S Handles, Fits P3, P4, P5. MORE...

5

B100594 Chrome warming rack. Fits D3, 2003 model. MORE...

6

DPA113 Stainless steel cooking grids for pre-2015 HX3 models.

• Heavy-gauge 1/4" rod construction
• Restaurant quality stainless steel
• 2 piece set
• Each panel measures 15 1/2" x 12 3/4"
• Single-level cooking surface

Note: This is the same as part# B101427.

Note: Part DPA113 is the factory authorized replacement for the following parts, which are no longer available:

• B101397

MORE...

8

B101061 Briquette Rack. Fits all size 3 grill head models. Manufacturer's Note: Some versions of this rack may include stainless steel extension brackets. See part DPA116 for Ceramic Flare Busters.

Note: Part B101061 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B063066

MORE...

9

B101436 Burner and venturi assembly. Fits Broilmaster H3 series grills. MORE...

10

B063065 Radiation Shield (Heat & Wind Deflector), Fits All Models. MORE...

11

B057805 Bridge Pin, Fits all models. MORE...

12

B057804 Hinge Pin, Fits all models. MORE...

13

DPA106 Adjustable Lid Stop Kit, All Models. Also replaces part #s B100421, B101231, B061281 and 061281.

Note: Part DPA106 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B076521
• BM:B100421
• BM:B101231

MORE...

14

P182 Burner Orifice #55 (LP) MORE...

15

P265 Orifice, (NAT) (20, 000 BTU) Fits VFHS-20/10T; VFSM, VFSV, VFSR-30, H3XN, P4XN (all) MORE...

16

B072218 Electronic ignitor head with two (2) male spade connectors. Fits 3/P4/P5/D3/D4

• Uses 1 AA battery (not included)
• Requires 7/8" mounting hole MORE...

17

B101420 VALVE Assy - LP. Uses orifice P182. MORE...

18

B101421 VALVE Assy - NAT. Uses orifice P265. MORE...

19

B073963 Shelf Pin and Nut, Fits All Models MORE...

20

B101517 Stick-on control panel label (for electronic ignition models), Fits P3/D3.

Note: Part B101517 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B072686

MORE...

21

B070084 Knob, Black (New Style), Fits P3/4/4, SR3, D3/4/5/2.
Also replaces part# B070286, which no longer available.

• Off position D-Value: 3 o'clock
• Knob diameter: 1 5/8"
• Socket diameter: 5/16"
• Knob shaft: 1/2"

Note: Part B070084 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B070286

MORE...

23

B101622 CONTROL PANEL SHIELD MORE...

24

B072684 Ground wire with female spade ends for battery-operated ignitors; 12" long. Fits All Electronic Models MORE...

25

B069747 Ground Lug, Fits All Models MORE...

26

B069743 Collector Box Spacer, Fits P 3/4 D 3/4/5

Note: Part B069743 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B069343

MORE...

27

B100446 Collector Box (Electronic Ignitor), electrode, and connector wire with female spade end. Please refer to DPP116 Kit if ground wire needed and two screws; does include sleeve # B069743. Fits P3/P4

Note: Part B100446 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B072701

MORE...

28

B069756 Hose and Regulator W/ Q.C.C. (female pipe fitting), fits all BRM LP models to 1999, SBG2500, 2501, 2801 MORE...

30

B101757 Burner bracket, sold as part # DPP118 that includes bolt, screw, nut and cotter pin, not shown in photo. Fits Q3X (all), and P3X, H3X, P4X, H4X with the igniter collector box attached to the burner.

Note: Part B101757 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B101648

MORE...

99

BCK1014 Conversion Kit, LP to Natural Gas. Fits Q3X and Q3PK1 grill heads. Includes:

• One (1) B101421 dual NG valve assembly
• Two (2) P208 orifices 1.45mm
• One (1) Conversion label NG B100033
• Gas conversion instructions MORE...

99

BCK1015 Conversion Kit, Natural Gas to LP. Fits Q3XN grill head. Includes:

• One (1) B069756 LP hose & regulator
• One (1) B101420 dual LP valve assembly
• Two (2) P315 orifices #60 drill size
• One (1) Conversion label LP B100273
• Gas conversion instructions MORE...

?

CLA-AC0394 High quality, long lasting ceramic briquettes. 59 flat top pyramid-shaped briquettes per box. Placed 1/2" apart, 59 briquetes will cover about 368 square inches. This is an area roughly 15" x 24".

• Top quality product
• Each briquette measure 2" x 2"
• Self cleaning
• Great heat distibution, retains heat longer
• Can be used on all grills that use briquettes or lava rock
• Use a single layer (multiple layers can reduce temperatures)

NOTE: These high quality ceramic briquetes are available in 59 count, 70 count, and 90 count qantities.

• 59 briquetes covers an area apprimately 15" x 24"
• 70 briquetes covers an area apprimately 17" x 26"
• 90 briquetes covers an area apprimately 17" x 33"

MORE...

?

BQ-3A BBQ'er choice porcelain grill briquets. The finest available.

• Self-Cleaning Porcelain Briquettes.
• Made of fired porcelain for even heat transfer.
• Virtually indestructible.
• About 56 pieces covers approximately 310 square inches.
• Made in USA.

NOTE: MHP model TJK requires two (2) bags.
NOTE: This is an Aftermarket part, NOT an original factory part.

Note: Part BQ-3A is the factory authorized replacement for the following parts, which are no longer available:

• BQ-5

MORE...

?

TG-1B Universal clip-on temperature gauge fits most grills. Find out if your grill is still hot at a glance.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

?

DPA116 Flare Busters Flat Ceramic Pads. For P3, T3, D3, H3. Package of 12. Each tile measures 7 1/4 " x 3 1/2". Used with B101061 rack. MORE...

?

DPP116 Collector Box Kit - (Mounts to Burner). Includes collector box/electrode/connector wire, ground wire and screws. Does not include sleeve # B069743. Fits: P3X, P4X, H3X, H4X all Q3X 2012 with H burner. MORE...
