Grill model: BSG262N

1

BR0001 Temperature Indicator Assy MORE...

2

BR0002 Grill Hood (req Handle and Heat Indicator), 26-in MORE...

3

BR0005 Handle, for 26-in Grill Hood MORE...

4

BR0008 Interior Light Assy, Right, 26/34/42-in MORE...

5

BR0009 Interior Light Assy, Left, 26/34-in MORE...

6

BR0010 Back Cover for 26-in Grill MORE...

11

BR0017 Warming Rack for 26-in Grill MORE...

13

BR0022 Firebox, 26-in MORE...

14

BR0025 Drip Tray, 26-in MORE...

15

BR0028 Badge, Broilmaster Logo MORE...

16

BR0029 Control Knob MORE...

17

BR0030 Bezel, Main Burner MORE...

18

BR0031 Switch, Pushbutton MORE...

19

BR0032 Control Panel, 26-in MORE...

20

BR0035 LED Heat Shield, 26-in MORE...

21

BR0038 LED MORE...

22

BR0039 LED Wiring Harness, 26-in MORE...

23

BR0042 Power Supply Harness MORE...

25

BR0044 Valve, Main Burner, Natural Gas MORE...

26

BR0045 Valve Grommet MORE...

27a

BR0046 Orifice, 2.08 mm MORE...

27b

BR0047 Orifice, 1.30 mm MORE...

30

BR0051 Transformer MORE...

31

BR0052 Gas Manifold, 26-in MORE...

32

BR0055 Heat Separator MORE...

33

BR0056 Heavy-duty, multi-level stainless Cooking Grid, Fits G Series Elite Edition 26-in grill models. MORE...

34

BR0059 Cast stainless BowTie Main Burner. Genuine Broilmaster part. MORE...

35

BR0060 Flare Control Vaporizer for Broilmaster G Series stainless steel grills. MORE...

36

BR0061 Regulator, Propane and Nat MORE...

37

BR0062 Bezel, Rear Burner MORE...

38

BR0063 Control Knob, Rear Burner MORE...

39

BR0064 Flame Carryover, 26-in MORE...

40

BR0065 Badge, Main Burner MORE...

41

BR0066 Hood Spring Assy, Right, 34 and 42-in MORE...

42

BR0067 Hood Spring Assy, Left, 34 and 42-in MORE...

44

BR0069 Lighting Tube, 26-in MORE...

?

CLA-WS0040 Universal premium quality stainless steel warming rack. You simply can't buy a better quality warming rack than this, which weighs in at almost 5lbs of solid 304 grade stainless steel. This super heavy-duty warming rack was made to replace the porcelain coated steel racks found on BBQ grills made by The Great Outdoors Grill Company, but can be used in any grill wide enough inside for the 24" rack.

• Far superior to the original porcelain coated steel rack
• Rests on your existing cooking grids.
• Solid 1/4" 304 stainless steel rods.
• Stands 3.75 inches tall.
• Made in USA.

NOTE: Before ordering this universal rack, please verify your grill has enough space to accommodate it. What's required? MORE...

?

BSABF12N Side Burner - Double, 12-inch, Slide in MORE...

?

BSABW16N Side Burner - Power, 16-inch, Slide in MORE...

?

BSACV26L Cover for 26-inch Grill on Cart MORE...

?

BSACV26S Cover for 26-inch Built-In Grill MORE...

?

BSAD1722 Single Door, 17-inch W x 22-in. H MORE...

?

BSAD2422 Single Door, 24-inch W x 22-in. H MORE...

?

BSAD2622D Double Doors, 26-inch W x 22-in. H MORE...

?

BSAF12DN Side Burner, 12-inch, Drop in MORE...

?

BSAMR26 Rotisserie Kit for 26-inch Grill MORE...

?

BSASL26 Insulated Sleeve for 26-inch Grill MORE...

?

BSATY Smoker Tray - Drop-In MORE...

?

BSAVR Infrared Sear Burner (replaces one Bowtie Burner) MORE...

?

BSAW1826R Drawer for Roll-Out Waste Container, 18-inch W x 26-in. H MORE...

?

BSAW1826T Triple Drawer, 18-inch W x 26-in. H MORE...

?

BSAW2022D Double Drawer, 20-inch W x 22-in. H MORE...

?

BSAW2022 Single Drawer - for Propane Tank, 20-inch W x 22-in. H MORE...

?

NG12 Quick disconnect 3/8" natural gas 12' Sturgis hose and coupling kit. The inside diameter of the hose is 3/8" and the outside diameter of the hose is about 5/8". Also replaces part# B100262.

Note: Part NG12 is the factory authorized replacement for the following parts, which are no longer available:

• BM:B100262

MORE...
